PIERCE 110V Electric Winch – 11,000 lb, 8" Drum (Planetary Drive) - Pre Order.
PIERCE 110V Electric Winch – 11,000 lb, 8" Drum (Planetary Drive) - Pre Order.
Couldn't load pickup availability
11 in stock
Compact 11,000 lb 110V Winch for Precision Pulling. Pre-Order.
The PS654-8EMK delivers 11,000 lb of pulling capacity with the efficiency of a built-in planetary gear reduction. This combination increases torque and holding power while maintaining a safe, slow line speed—ideal for commercial docks and shop hoists. Each unit includes the PBM1 cradle mount and ships in 1–2 business days.
- 11,000 lb rated capacity with planetary gear assist
- 8" drum supports up to 100' of 3/8" wire rope
- 110V AC operation with durable worm-gear construction
- Includes PBM1 cradle mount and wired control
Applications: Boat docks, small industrial lifts, equipment positioning, and maintenance bays.
⚠️ A certified electrician is required to install this product. Do not attempt installation without proper certification or training.
Included:
| Specification | Details |
|---|---|
| AMP DRAW | 17.4 |
| BRAKE TYPE | Worm Gear Brake |
| CLUTCH TYPE | Dog |
| CONSTRUCTION | Cast Metal |
| DRUM ROTATION | Counter-Clockwise (Underwound) |
| DRUM SIZE | 3 ½ in. x 8 in. |
| GEAR RATIO | 728.5:1 |
| GEAR TYPE | Worm Gear |
| MAX CAPACITY (LBS.) | 11000 |
| MAX LINE SPEED | 4 fpm |
| MOTOR (HP) | 1.5 |
| OPERATING VOLTAGE | 110 Volts AC |
| POWER SOURCE | Electric, AC |
| RECOMMENDED WIRE | 12-14 gauge |
| RECOMMENDED WIRE ROPE | ⅜ in. x 100 ft. |
Manual: https://www.piercearrowinc.com/pages/docs/psw-654-series-winch-manual
Spec Sheet: https://www.piercearrowinc.com/pages/docs/psw-654-series-winch-manual
Limited Lifetime Warranty
Mechanical Parts guaranteed free of Defects.
- Mechanical parts are guaranteed to be free of manufacturer defects.
- Parts will be replaced at the manufacturer's discretion.
Electrical Components have a 2 Year Warranty
- Warranty ensures that electrical components are free from defects.
- The Warranty period is taken from the date the goods leave our factory, although we will accept a later date if the Distributor can confirm date of purchase.
Conditions
- Does not include normal wear and tear, misuse, water damage or other forms of abuse.
- Electrical components must have proper wiring verified and be protected by appropriate fuses, breakers, and power disconnects to qualify for any warranty coverage.
- This warranty only covers the original products sold by PIERCE. Labor, down time, loss of work and other expenses are not included in this warranty.
- You must contact us first to receive a return merchandise authorization number and instructions to return and receive warranty.
- All return shipping logistics and costs are non-refundable and the responsibility of the buyer.
- Call us to explain the problem, making sure you have both the model number and the serial number on hand. Often, we can resolve the matter over the phone.
